Lesson 12

Partition Rectangles into Squares

Warm-up: Estimation Exploration: Fill it Up (10 minutes)

Narrative

The purpose of this Estimation Exploration is to practice the skill of making a reasonable estimate. Students consider how the placement of the first 2 squares can help them think about the total number of squares needed to fill the rectangle (MP7). These understandings will be helpful later when students will need to partition rectangles into equal-size squares.

Launch

  • Groups of 2
  • Display the image.
  • “How many little squares would fill the rectangle?”
  • “What is an estimate that’s too high?” “Too low?” “About right?”
  • 1 minute: quiet think time

Activity

  • “Discuss your thinking with your partner.”
  • 1 minute: partner discussion
  • Record responses.
  • Draw equal-size squares to show:
Rectangle.
  • “Would you like to revise your thinking?”
  • 1 minute: quiet think time
  • Share responses.

Student Facing

How many little squares would fill the rectangle?

Rectangle partially partitioned to show the beginning of one row. Two equal sized squares.

Record an estimate that is:

too low about right too high
\(\phantom{\hspace{2.5cm} \\ \hspace{2.5cm}}\) \(\phantom{\hspace{2.5cm} \\ \hspace{2.5cm}}\) \(\phantom{\hspace{2.5cm} \\ \hspace{2.5cm}}\)

Student Response

Teachers with a valid work email address can click here to register or sign in for free access to Student Response.

Activity Synthesis

  • “How did the second image help you revise your thinking?”
  • Consider asking, “How could you tell that 11 would not be a reasonable estimate?” (The bottom row already has 4, so the 2 bottom rows will have 10. It has to be more than 11 because there is another row to fill.)

Activity 1: How Many Squares? (15 minutes)

Narrative

The purpose of this activity is for students to partition rectangles to create rows and columns of equal-size squares. In the launch, students build an array with tiles and then represent it on a rectangle with tick marks as guidance. They will partition rectangles without tick marks in the next activity.

MLR2 Collect and Display. Synthesis: Direct attention to words collected and displayed from the previous lessons. Include the word “partition.” Invite students to borrow language from the display as needed, and update it throughout the lesson.
Advances: Conversing, Reading

Required Materials

Materials to Gather

Launch

  • Groups of 2
  • Give students rulers and inch tiles.

Activity

  • “Use 8 tiles to make a rectangle. Your tiles should be in 2 rows.”
  • 1 minute: independent work time
  • “Now, draw lines in the rectangle to show the squares. It should have the same number of equal-size squares as the rectangle you made out of tiles. You may use a ruler if it helps you.”
  • 1 minute: independent work time
  • “You will draw lines to partition 2 more rectangles into equal-size squares. You can also use the tiles to build it first, if that helps.”
  • 10 minutes: independent work time

Student Facing

  1. Build a rectangle with 8 tiles arranged in 2 rows. Use a ruler to partition the rectangle to match the rectangle you made.

    Rectangle. Length sides, 3 evenly spaced tick marks each. Width sides, 1 tick mark each.

  2. Use a ruler to partition the rectangle using the tick marks as a guide.

    Rectangle. Length sides, 4 evenly spaced tick marks. Width sides, 2 evenly spaced tick marks.

    1. How many rows of equal-size squares did you make?
    2. How many columns did you make?
    3. Write 2 equations to represent the total number of equal-size squares.
  3. Use a ruler to partition the rectangle using the tick marks as a guide.

    Rectangle. Length sides, 3 evenly spaced tick marks each. Width sides, 2 evenly spaced tick marks each.

    1. How many rows of equal-size squares did you make?
    2. How many columns did you make?
    3. Write 2 equations to represent the total number of equal-size squares.

Student Response

Teachers with a valid work email address can click here to register or sign in for free access to Student Response.

Advancing Student Thinking

If students create equations that match the total number of squares, but do not represent the sum of squares in each row or the sum of squares in each column, consider asking:

  • “How does your equation match the array?”
  • “Can you write an equation with equal addends that shows the sum of each row or column?”

Activity Synthesis

  • Invite 12 students to share their rectangles and equations for their rectangle with 3 rows and 5 columns. (\(3 + 3 + 3 + 3 + 3 = 15\) or \(5 + 5 + 5 = 15\))
  • Draw a rectangle and partition to show:
    Rectangle.
  • “How is this partition different from what we did in this activity?” (The squares aren’t the same size and the last column has 4 not 3.)

Activity 2: Partition Rectangles (20 minutes)

Narrative

The purpose of this activity is for students to partition rectangles into rows and columns of equal-size squares. They use tiles to help them see how to draw lines to partition the rectangles. Although it is important for students to use what they know about the structure of arrays and composing rectangles from squares to partition the rectangles (MP7), it is not necessary that students’ drawings are perfect. As long as it is clear that the student intended for the squares to be equal in size and they can articulate their reasoning. If their squares are significantly different or result in more squares in one column or row than another, offer a ruler and consider having students trace tiles for practice or guidance.

Action and Expression: Develop Expression and Communication. Give students access to 1-inch grid paper to get their thinking started, and create an array with the inch tiles. Have students transfer what they made on the grid paper to the open rectangles given. The concrete image transferred to the more abstract image may help some students visually.
Supports accessibility for: Visual-Spatial Processing, Organization

Required Materials

Materials to Gather

Launch

  • Groups of 2
  • Give students rulers and inch tiles.

Activity

  • “You will be partitioning rectangles. For the first one, work with a partner to make a rectangle using tiles to help you plan, and then partition one of the rectangles to match.”
  • 5 minutes: partner work time
  • Monitor for a group who used each of the rectangles.
  • Selected groups share.
  • “How did you decide which drawn rectangle to use to represent your tile rectangle?” (Our rectangle had 2 tiles in each row so we used the taller rectangle.)
  • “Could you have used the other rectangle?” (No, because the squares wouldn’t be the same size.)
  • 30 seconds: quiet think time
  • 1 minute: partner discussion
  • Share responses.
  • “For the next 2 rectangles, work on your own to partition them. Remember that all the squares should be the same size. After you are done, compare with your partner.”
  • 6 minutes: independent work time
  • Monitor for students who have a solid strategy for making equal-size squares. Choose at least 1 student who thought about the number of squares first and 1 who drew the lines first and then counted the squares.

Student Facing

  1. Use 12 tiles to make a rectangle. Split one of the rectangles into equal-size squares to match your rectangle made of tiles.

    Rectangle.
    Rectangle.
    1. Write 2 equations to represent the total number of squares.
  2. Split this rectangle into equal-size squares.

    Square.
    1. Write 2 equations to represent the total number of squares.

  3. Split this rectangle into equal-size squares.

    Rectangle.
    1. Write 2 equations to represent the total number of squares.

Student Response

Teachers with a valid work email address can click here to register or sign in for free access to Student Response.

Activity Synthesis

  • Invite previously identified students to share how they partitioned their rectangles.
  • “What strategies did you use for making your squares all the same size?” (I knew I wanted _____ squares, so I did _____ lines across and down. I started by making my rows, then made the lines for the columns, and then saw how many squares it made.)

Lesson Synthesis

Lesson Synthesis

Display a variety of arrays and rectangles from the unit, such as:
4 pairs of socks.
Array.
Array.
Array.
Rectangle.
BArray. Two rows of 3 eggs.

“In this unit you learned about even and odd numbers and different types of arrays. Looking at these images, think about 1 thing you could say about each one. What are some things that are the same or different?”

Share and record responses.

Cool-down: How Many Squares? (5 minutes)

Cool-Down

Teachers with a valid work email address can click here to register or sign in for free access to Cool-Downs.

Student Section Summary

Student Facing

In this section, we learned that arrays are groups of objects that are organized into rows and columns. Arrays have the same number of objects in each row and the same number of objects in each column. We practiced different ways to count the objects in an array and used expressions with equal addends to show that you can find the total objects in an array by adding the sum of each row or the sum of each column. We also learned that rectangles can be composed of an array of equal-size squares. We practiced partitioning rectangles into rows and columns of equal-size squares.

Array.
Tray of waffles.
Rectangle. Partitioned into 4 rows of 5.

\(4 + 4 + 4 + 4 + 4 = 20\)       or       \(5 + 5 + 5 + 5 = 20\)
